The Farmall utility M series tractor is the latest addition to the Farmall lineup, designed to meet your demanding needs. The ActiveDrive 4 transmission brings new levels of power and performance to your workplace in two outstanding models, the 110M and 120M.
Fuel-Efficient, Clean Engine
Under the hood of the new Farmall M series tractor is a powerful FPT 3.4 L, 4-cylinder engine with Tier 4 B/Final emissions, a turbo-intercooler and high torque values. The Farmall M series combines power with efficiency.
Smooth Shifting
ActiveDrive 4 semi-automatic transmission uses button-operated seamless gear shifting, maximizing comfort with smooth gear shifts. The tractor comes standard with 16 forward and 16 reverse gears but an optional creeper option is available with 32 forward and 32 reverse gear . The ActiveDrive 4 transmission covers a wide range of speeds, from under .2 MPH to 25 MPH.
Additional features such as the electro-hydraulic power shuttle, power shuttle sensitivity settings, automatic 4WD and automatic differential lock, deliver efficiency and comfort throughout the day.
Special Waterproof Transmission Farmall M tractor models can be fitted with an optional waterproof transmission for producers needing trouble-free operation in even the most challenging conditions. Special guards mounted on the axle and transmission prevent water and mud from penetrating.
Ready for Work
An electro-hydraulic power take-off (PTO) clutch, two PTO speed options (540/1000 rpm or 540/540E/1,000 rpm), and automatic PTO (Auto PTO) function make the Farmall M tractor ready for work. Monitor the PTO speed on a digital indicator in real time during operation. Auto PTO lets you engage or disengage the PTO at a predetermined hydraulic arm/ lever height.
All-day Comfort
Comfort is not overlooked in the Farmall utility M series tractor. A spacious cab with air conditioning, ergonomic control levers, air-suspension seat and sunroof make this a relaxing workspace no matter how long the days. The air-suspension seat adjusts the suspension to suit your personal preference.
Meet All Your Needs, in All Conditions
Electro-hydraulic components ensure efficiency when working with a variety of agricultural attachments. Features include electronic draft control, hydraulic lift capacity of 8,809 pounds, six hydraulic outlets, fender mounted hydraulic controls, and hydraulic top link.
A standard electronic hitch control system makes it easy to control heavy agricultural attachments. Adjust settings in the electro-hydraulic system to meet all your needs, in all conditions.
Parts & Service
Only genuine Case IH parts were made specifically for your machine and designed for peak performance. Find everything you need from filters, fluids, safety equipment and Case IH merchandise, to owners manuals, parts diagrams, paint, and batteries at the Case IH parts store.
