FARMALL 100A | |
|---|---|
ENGINE | |
FPT - EU Stage V [Hi-eSCR2] | ✓ |
Rated power acc. ECE R120 [kW/hp] | 74 / 100 |
Number of cylinder / capacity [cm3] | 4 / 3,600 |
Max torque [Nm] | 450 @ 1,300 rpm |
Torque rise [%] | 47 |
Diesel / AdBlue capacity [litres] | 130 / 14 |
TRANSMISSION | |
12x12 ManualDrive - with Powershuttle, 40 kph, optional creeper | ✓ |
HYDRAULICS | |
Open Center pump - 82 l/min | ✓ |
Up to 3 mechanical rear remotes valves | ✓ |
Mechanical mid mounts, incl. joystick for frontloader | 2 |
PTO | |
540/540E/1,000 @ 1,938/1,535/1,926 rpm | ✓ |
Electro-hydraulic activation | ✓ |
REAR LINKAGE | |
MDC mechanical draft control Lift-O-Matic - max. lift capacity 4,400 kg | ✓ |
CONFIGURATION | |
4-pillar cab with air conditioning, roof window, radio & passenger seat | ✓ |
Mechanical front hitch with front PTO optional | ✓ |
Pneumatic trailer brake | ✓ |
FRONT LOADER CASE IH L3815A | |
Mechanical self leveling, FITLOCK2+ System®- automatic hitching incl. multi-connection, | ✓ |
SHOCK ELIMINATOR suspension, EURO implement carrier | ✓ |
3.80 m max. lift height @ implement pivot | ✓ |
1,650 kg max. payload 600 mm from implement pivot axis | ✓ |
