RB456 HD Pro | |
|---|---|
BALE DIMENSIONS | |
Bale diameter [cm] | 90 / 165 |
Width [cm] | 120 |
TRACTOR REQUIREMENTS | |
Minimum PTO power [kW/hp] | 88 / 120 |
Overall protection | Cut-Out Clutch |
PTO speed | 1,000 |
PICK-UP | |
Width, effective (DIN 11220) [m] | 2.3 |
Number of tine bars | 5 |
Windguard type | Roller |
Pickup wheels | Gauge wheels (15/6.00 - 6) |
FEEDER & CROP CUTTER | |
Type | Rotor „V“ shape |
Feeding system | Rotor Cutter 25 knives |
Top Assist Roll | ✓ |
Active Drop Floor | ✓ |
BALE FORMATION | |
Type | Hydraulic |
Number of belts | 4 x 273 mm endless |
Density control | In-cab control through monitor |
WRAPPING SYSTEM | |
Net wrapping system | Duckbill net feeding |
Net storage | 1 active + 2 spare |
Net coverage | Edge to edge |
MONITOR | |
Baler control system | AFS Pro 700 |
TYRES AND BRAKES | |
Available sizes | 500/55-20 or 620/40-22.5 |
Brakes | Hydraulic or Pneumatic |
BALER DIMENSIONS | |
Width on 500/55-20 tyres [mm] | 2,742 |
Width on 620/40-22.5 tyres [mm] | 2,910 |
Total length [mm] | 4,865 |
Total height [mm] | 3,170 |
Weight [kg] | 3,500 |
OTHER EQUIPMENT | |
Automatic chain lubrication | ✓ |
Automatic chain greasing | Option |
LED under shield service lights | Option |
Beacon light | Option |
