QUANTUM 120N | |
|---|---|
ENGINE | |
FPT - EU Stage V (UltraCompact Hi-eSCR2) | ✓ |
Rated power acc. ECE R120 [kW/hp] | 88 / 120 |
Number of cylinder / capacity [cm3] | 4 / 3,600 |
Max torque [Nm] | 518 @ 1,300 rpm |
Torque rise [%] | 42 |
Diesel / AdBlue capacity [litres] | 90 / 11 |
TRANSMISSION | |
ActiveDrive 2 - 24x24 gears, 2-speed Powershift, 40 kph | ✓ |
Adjustable Powershuttle | ✓ |
Power Clutch | ✓ |
HYDRAULICS | |
Open Center pump 80 l/min + 36 l/min steering pump | ✓ |
Rear Electro-Hydraulic Remotes + Mid-Mount Remotes | 4 |
Incl. free return | ✓ |
Optional Rear Power Beyond | ✓ |
PTO | |
540 / 540E / 1000 @ 1,958 / 1,535 / 2,000 rpm incl. stationary PTO | ✓ |
Electro-hydraulic PTO engagment | ✓ |
Soft start, external control | ✓ |
REAR LINKAGE | |
EDC - max. lift capacity 2,200 kg, 2 external lift rams | ✓ |
Rear fender control | ✓ |
CONFIGURATION | |
Comfort Cab incl. Category Cab 4 filter (Twin filter system) | ✓ |
Digital dashboard with Encoder | ✓ |
Suspended front axle with 3 suspension modes | ✓ |
Priemium Air Seat | ✓ |
Full LED Package 8 LED work lights | ✓ |
Optional FHPL & FPTO | ✓ |
Total width from 1.05 -2.50 m | ✓ |
