55 - 75 HP

JXT Series

Simple, reliable and economical, JXT tractors are perfect for small farms yet robust enough to use as utility tractors in any farming business. These are machines that will always deliver a high return on your investment, no matter what you ask of them.
FIND A DEALER
RATED POWER

35 - 75 Rated Power HP

TRANSMISSION

Mechanical

CAPACITY

2,365 - 3,908 cm3

MAXIMUM PUMP FLOW RATE

210 l/min

JXT Series



    FIND A DEALER

    JXT Series

    Engineered for High Output

    A choice of engines and transmissions for maximum versatility.

    The Right Transmission to Meet Your Needs
    JXT tractors reliably deliver high performance and versatility with transmissions engineered to deliver high output and power to the ground. With different transmission options available for a wide variety of applications, you can choose the one that exactly meets your needs. Three smaller models feature a 8x2 or optional 8x8 constant mesh gearbox. The two bigger models come with a basic 8x2 transmission variant or, optionally, a partly synchronized transmission with 12x3 gears. And if ultra-slow working speeds are required it's also possible to specify a creep speed reduction gearbox in addition to the main transmission.

    FPT Engines
    JXT tractors come with world-renowned FPT engines, (55 hp - 75 hp models) or Simpson engines (35 hp to 47 hp models) known for ruggedness, reliability and excellent torque characteristics. With their high engine backup torque, JXT tractors can deal effortlessly with sudden loads at constant engine rpm. They deliver more power in the working range with a lower drop in rpm. In the optional Tier 3 version, the turbocharger increases the oxygen available to the engine, optimizing fuel combustion.

    Explore the Features

    • The JXT is designed to provide you with a comfortable work environment, with plenty of space and all the controls within easy reach. Outstanding visibility all round and easy access make it ideal for all the tasks around the farm. Hopping on and off the JXT tractor is easy and safe, thanks to the large step plates and wide steps.

      Ergonomic layout

      • Easy access: large plates and wide steps
      • Wide platform: ample space for the operator
      • All controls placed within perfect reach
      • Optional DeLuxe seat with bottle holder

    • JXT tractors are designed to work with all types of implements, with the hydraulic, PTO and drawbar power to handle them effortlessly.


      More PTO Power

      JXT tractors optionally feature ground speed PTO, where the speed is proportional to the tractor's travel speed. The directly driven PTO enables high output at low engine speed, prolonging the life of vital components, enabling your tractor to work at maximum fuel efficiency and the lowest possible operating costs.


      More Lifting Power

      Using a system of 24 sensitivity points, the JX55T/JX75T hydraulic system adjusts the working depth of implements according to the soil resistance and the requirements of the application. The Lift-O-Matic™ rear linkage control with height limiter ensures accurate and fast switching between the implement working position in the field and the correct lift height on the headland. The standard three-point hitch has a lift capacity of 1,500kg kg and, if you need more, an optional assist ram provides extra lifting capacity, increasing it to 2,000 kg on the JX55T and JX75T.

    • The JXT Compact tractors (JX35T / JX40T / JX45T) are simple and reliable models designed with the operator in mind.


      An exceptional operating experience

      The JXT Compact tractors provide a comfortable work environment with ample space and ergonomic layout of the controls. They are easy to operate and, with the one-piece hood, simple to maintain.


      Powerfully economical

      Ranging from 35 to 47 hp and available in two- and four-wheel-drive versions, these compact tractors feature rugged and reliable three-cylinder, naturally aspirated engines that deliver a powerful performance with exceptionally low operating costs. If you need a big performance in a simple, economical and reliable compact tractor below 50 hp, the JXT Compact is your answer.

    • Case IH’s AFS Connect solution now brings even more power to leverage on our JXT series tractors. Use the factory installed connectivity together with our mobile-based AFS Connect app to gather insights on each and every task.

      Stay informed with instant machine status updates, proactive alerts on vehicle usage and reports showing how every field task is performed. Giving you the data you care about.

      AFS Connect on-board also enables simplified servicing and diagnostics through our Digital Dealer Control Rooms - constantly working behind the scenes to maximise your uptime.
