Small Square Balers

SB Series Small Square Balers

Bale Better Than The Rest With Improved Equipment

High-quality baling isn’t just about productivity — it’s also about quality. A proper baler should help you achieve more in a day while offering accurate, stable and consistent baling at high speeds.

With two models to choose from, you’ll get the job done right knowing you’re relying on extra-wide pickups, smooth rotary feeding systems and other best-in-class advancements.

Plenty of Sturdy Tines and an Adjustable Pickup Gauge Wheel
The pickup on the Case IH small square baler series is designed for high productivity.

Tines
- Sturdy, closely spaced, curved finger tines gently lift the crop while keeping leaves intact
- Rugged tine bars run on sealed ball bearings
Standard pickup gauge wheels adjust to five positions
- Guides the pickup through field contours
- Pick up every bit of the windrow
Raise Pickup for Transport
- Manual latch or optional hydraulic pickup lift
A Uniform, Well-Shaped Bale
Huge 283-sq in. (1,826-sq cm.) feed opening allows SB balers to gather large, uneven windrows. A uniform, well-shaped bale is produced by the dependable Case IH feeding system.
- High-throughput rotary feeding system delivers high capacity in any crop
- Heavy-duty, double-rotating tines overlap to feed crop smoothly and continuously
- Adjustable double-packer fork folds hay into the bale chamber
- No-plug feeding system effortlessly moves crop from the pickup area to the bale chamber with minimum shatter loss
Easy Bale Density Control
All SB Series balers allow for easy bale density control by adjusting the tension applied to the bale chamber. For manual density control, tension springs are an economical choice.
- Provides "set-it-and-forget-it" convenience
- Ensures consistent bale weight and density
Handle Challenging Baling Conditions
Case IH small bales hold up to handling from the rack to the elevator and from the barn to the bunk.
Dependable Gear-Driven Twine Knotters
- Hard-surface material at all wear points
- Bill hooks are chrome plated for extra durability and reduced maintenance
- SB541 is also available with a gear-driven wire twister
Large-Capacity Twine Storage Increases Field Time Between Refills
- SB531 — load six balls of twine
- SB541 — load eight balls of twine
- SB541 wire-tie version features four-coil wire storage
