Farmall JX

With four models between 75 HP and 110 HP, whatever the power requirements of your business, there will be a Farmall JX to fit your needs.


The Power to perform

The Farmall JX range are all powered by upgraded FPT Industrial S8000 Series, Tier 3 turbocharged engines, carefully tuned to provide optimum fuel efficiency and maximum power. A new ergonomically designed CAB or an open station ROPS platform configuration are available to suit your list of choice. The Farmall JX range features a range topping 110 HP model offering an entirely new level of power and performance.

Explore the series

  • Slim pillars, large mirrors and a broad windscreen mean that, with a Farmall JX, the view to loaders and trailed or mounted implements is among the best in this horsepower sector.

  • Logically-positioned controls with clear, concise instrumentation are part of the package that make tasks less arduous when working with a Farmall JX. Levers and switches fall easily to hand, making operation instinctive after only a short time at the steering wheel.

  • An optional hydraulic powershuttle makes for easy forward / reverse manoeuvring, especially during loader work.

  • The optional new high visibility roof screen for the Farmall JX makes it well-suited to loader work, while a revised lighting package turns night into day when working on after dark. The worklights are integrated into the roof for protection, yet are fully adjustable.

  • Farmall JX tractors benefit from 40,1 l/min open-centre hydraulic systems, 51,7 l/min high flow pump or 63 l/min mega flow options and can be equipped with up to three rear remote valves. Rear linkage lift capacity is up to 4700 kg at ball ends. 540 rpm PTO is standard together with ground speed PTO. Optionally, you can choose between 540/540E rpm or 540/1000 rpm and servo-assisted PTO engagement.

  • Turbocharged and intercooled, mechanical injection Tier 3 engines provide reliable power, day in, day out. Simple, robust design results in trouble-free, long-life working, and reduced maintenance requirements.

  • A wide range of transmissions are available, including a 12 x 12 synchromesh, a 20 x 12 creeper speed transmission or a 12 x 12 Powershuttle, offering clutchless direction changes. Top travel speeds of 30 kph or 40 kph are available on Farmall JX tractors, and for additional assurance when stopping, whatever the conditions, a braked front axle is optional on all models.



Number of cylinders
Emission Level
Capacity (cm³)

Engine Performance

Standard Transmission

Optional Transmission 1

Optional Transmission 2

Optional Transmission 3

Power Take Off

Front PTO and hitch

Drive and Steering (Driveline)

Hydraulic System
