Rows
6 – 48
Spacing
15" – 40"
Transport Width
12' 4" – 26’ 8”
Frame Size
7"x7" – 12"x12"

2000 Series Early Riser Planter

Maximize Yield Potential

This easy maintenance planter allows for a customizable seeding depth and plants with accuracy by combining a rugged row unit and accessible T-handle depth adjustment. With the industry’s most accurate technologies, you can achieve high-efficiency planting that adapt to unique field conditions.

Explore Features

Split-row Planting
Row Unit
Seed Delivery
Bulk Fill System
Carrier System
AFS Technology
Precision Planting
Maintenance & Uptime
Customization Options

New for 2023

New Year, New Model, New Updates

The All-new 2110 Early Riser Rigid Mounted Planter
- The first factory-equipped high-spec rigid mounted planter: Operators will be able to achieve maximum efficiency across bedded crops, flood irrigation and more with the 2110 Early Riser planter.
- A durable 7”x7” main frame tube design provides a solid foundation for the optional hydraulic down force system to ensure consistent, accurate seed placement.
- The 2110 Early Riser rigid mounted is available in six and eight row configurations with row spacing options of 30”, 36”, 38” and 40”
- High-tech features including automated Speed Adjusted vacuum control, in-cab control of residue management and closing systems as well as standard individual row rate and section control.
- Minimized weight and reduced hydraulic demand deliver greater fuel and power efficiency when paired with lower-horsepower tractors.
Increased Capacity
- Available on 2150 Early Riser front-fold planters, achieve increased run time between liquid product fills with 540 gallons of capacity.
- New optional split bulk-fill scale tanks on the 2150 Early Riser planter allow for increased tendering and filling efficiency, as well as greater acre coverage.
- Split scale tanks feature easy access for filling and low tank heigh with rearward visibility, and can be monitored from three separate locations: in the cab, on the rear-fill platform or on the ground via the Cab Control wireless app.
AFS Pro 1200
- Latest software updates enable operators to use a single display for all tractor and planter functions.
- View important planter functions while performing another function on the display with six customizable run screens.
- High-resolution mapping can be configured to display coverage, varieties, planter ride, spacing, ground contact, skips and more.
Dealer-installed 48^th Row Option
- Add a 48th row to your current 47-row 2160 Early Riser front-fold trailing planter for added productivity.
- This kit is easy for dealers to install with bolt-on brackets.

Split-Row Planting

2150S Split-row Model

The Early Riser 2150S front-fold trailing planter provides the agronomic benefits of split-row planting with greater in-field productivity:

A fertilizer capacity of 525 gallons with 100 bu. of seed capacity maximizes in-field productivity while individual tank scales provide easy, even filling.
In-cab hydraulic row unit lift control allows operators to easily convert from 15- to 30-inch spacing.
Exclusive, industry-leading offset row unit design helps increase residue flow with minimal plugging opportunities.
Exceptional ground-following capabilities are made possible by 30 degrees of total wing flexibility, while the hydraulic wing downforce option improves depth control.

Row Unit

Built for Accuracy at Your Speed

Recent field testing shows our industry-leading new Early Riser planter row unit is where speed, precision and performance meet. The unit is high-speed capable while delivering accurate seed placement, net effective stand and harvest data.

Watch this video to learn how the Early Riser row unit is designed for superior agronomic performance.

Vertical Row Unit Travel

Sixteen inches of vertical row unit travel improves performance in varied terrain while providing greater clearance for residue managers. Cast-iron row unit is built with larger, common hardware and fewer parts.
Opening System

Larger diameter and thicker Earth Metal^® offset opener blades are agronomically designed to slice through residue and tough soil conditions.
Furrow Management System

Pulled gauge wheels with soil relief grooves eliminate sidewall compaction and control soil flow through changing ground speeds. The furrow forming point creates the industry’s only flat-bottom seed trench.

Downforce Management

Through up-or-down hydraulic pressure, automatic and row-by-row DeltaForce^® achieves consistent weight on the gauge wheels for unparalleled depth control. Or select air downforce with or without in-cab gauge wheel feedback.
Floating Residue Management System

CleanSweep^® air cylinders allow for in-cab adjustments of residue manager ride to accommodate soil and residue conditions.
Two-stage Closing System

Inverted closing disks zip the trench closed, placing high-moisture soil directly onto the seed. The press wheel ensures proper seed-to-soil contact.

AFS Technology

Putting Technology to Work for You

Advanced Farming Systems (AFS) from Case IH help you reduce overlaps and skips; visualize high-resolution, as-applied planting data in real time; control inputs by prescription; and monitor planter performance — all from one display.

Control System Options
- Choose from either the AFS Pro 1200 or AFS Pro 700 display to match your operation and equipment needs:
  - AFS Pro 1200: Offers a single-screen solution with an enhanced user interface for AFS Connect™ Steiger® or Magnum™ series tractor operators, delivering the full suite of AFS Pro 1200 planter software capabilities.
  - AFS Pro 700: Offers a single-screen solution for other Case IH tractor models.
- Planter data can be shared with your home computer or trusted third-party advisers.
- AFS Connect vehicles allow remote data sharing via the AFS Connect Farm portal on web and mobile
AFS Pro 1200
Take as-applied mapping to the next level with:
- Advanced mapping capabilities
- Row-by-row visualization
- Split-screen mapping
- Six customizable user defined windows
- 3D implement modeling for accurate coverage maps
Learn More about the AFS Pro 1200
AFS Connect Farm Visualization
- Use highly accurate RTK-generated boundaries or manually create and upload your own.
- Collected data coordinates and spatial data sorting automatically tie all activity to a specific field.
- Easily create field map layers such as planting, application, variety maps and more.
- Use your crop consultant’s digital scouting reports and UAV data as layers in your farm tab.
Learn More about AFS Connect Farm

Seed Delivery

Precise Per-Row Seed Metering

To achieve the perfect picket fence stand, you need a seed meter capable of delivering accurate and consistent seed singulation, populations and in-row spacing. The all-new seed meter and electric drive at the heart of the new 2000 series Early Riser planter row unit do just that. And it does it at your speed.

Get an inside look at how Advanced Seed Delivery™ provides the most precise control from the meter to the furrow.

Precise Per-Row Seed Metering

vSet® 2 Seed Meter with vDrive® Electric Drive Motor

Row-by-row overlap control and curve compensated spacing deliver optimal seed singulation and spacing. A simple design provides tool-free crop changes and reduces mechanical drive components.
Advanced Seed Delivery (ASD)

For the most accurate seed delivery and placement to and in the trench, the 2000 series ASD option includes the new SpeedTube from Precision Planting. Available for corn and soybeans, the SpeedTube™ uses a flighted belt to control the delivery of the seed from the meter to the furrow, eliminating the drop and tumble variability of traditional gravity drop tubes, especially at high speeds.

Bulk Fill System

Engineered to Deliver

Our 2000 series Early Riser planters are equipped with bulk-fill tanks to provide reliable seed delivery from the tank to the mini-hopper — no matter the seed population. The 2160, 2150 and 2140 models feature two bulk-fill tanks, and the 2130 model features one 50-bushel tank. Plus, optional 1.9-bushel, on-row individual hoppers are available on all 2130 and 2150.

Carrier System

Reduced Compaction & Better Maneuverability

Extend your planting window with the Rowtrac™ Carrier System, currently available as a factory-installed option. With increased flotation over a wheeled carrier, this carrier system reduces compaction and improves yield potential in wet spring conditions. Plus, it provides better maneuverability with transport steering and excellent ground contact on uneven terrain with fore-aft track oscillation.

Watch this video to discover more unmatched features of the Rowtrac Carrier System.

Precision Planting

Fit the Way You Farm

As the only planter engineered and built with Precision Planting^® components, you can customize your planter with the most accurate planting technology, direct from the factory. And, while others may offer some of these components, only the 2000 series Early Riser planter combines Precision Planting technology with the industry’s most agronomically designed row unit.

2000-Series_Early-Riser-Planter_Precision-Planting

DeltaForce^®
- DeltaForce hydraulic down force helps achieve the ultimate row-by-row control across varying soil conditions and speeds
- Automatically provides the required up or down pressure to achieve consistent weight on the gauge wheels, resulting in highly accurate seed depth
- Measures gauge wheel load 200 times per second, triggering hydraulic adjustments to add or remove weight five times every second
CleanSweep^®
- Floating residue managers with CleanSweep air cylinders provide flexibility and enhanced performance to clear even the toughest residue — without distributing soil
- Make in-cab ride adjustments from the tractor cab through your AFS Pro 700 monitor
- Simply add down pressure for tougher no-till conditions, or add up pressure for soft and mellow conditions

Maintenance & Uptime

Easy Service Access & Simplified Adjustments

Many components of our 2000 series Early Riser planters – including the metering system and row unit settings – provide tool-free crop changes and adjustments.

Plus, we’ve eliminated all the mechanical components – hex shafts, bearings, couplers, sprockets, chains and clutches – needed to turn a conventional planter. Fewer things to go wrong means reduced, simpler maintenance.

Customization Options

Built to Your Specs

Direct from the factory, each 2000 series Early Riser planter is configured to meet your specific needs and fit perfectly into your cropping practices. Like never before, you can customize your planter to your farm’s soil types, terrain, fertilizer and chemical application needs, and crop residue management preferences.

2000-Series_Early-Riser-Customization-Options

Crop Protection
- AMVAC SmartBox^® option delivers granular insecticide in-furrow
- Closed on-row system helps minimize exposure to granular insecticides and provides superior crop protection
- Electronically controlled metering for precise application, while adjusting for changes in ground speed
- Available row by row shut-offs help reduce input costs
Fertilizer Application Options
- Liquid fertilizer system is designed for accurate application at speeds from 3 to 10 mph
- Centrifugal pump accurately delivers a broad application rate range
- On 2160, 2150 and 2140 planter models, factory-installed seed-fertilizer combination units feature a 400- to 600-gallon liquid fertilizer capacity plus bulk-fill seed hoppers
- Factory-available fertilizer, including all toolbar and row unit distribution to the furrow, is available for the 2130 planter model; tractor-mounted tanks required
- Available row-by-row shut-offs help reduce input costs

See The Early Riser Planter In Action

See the Performance for Yourself

See the Performance for Yourself
Hear What Customers Are Saying

Hear What Customers Are Saying
Watch it in Action

Watch It in Action

Current Models

2110 Rigid Mounted
A 6- and 8-row planter supporting 30-, 36-, 38- and 40-inch spacing with a lower machine weight. Perfect for lower horsepower tractors, as well as regional farming practices with bedded crops (i.e., cotton & peanuts) and flood irrigation.
2130 Stack-fold
A 12-row planter with 30-, 36-, 38- or 40-inch spacing , 16-row planter with 30-inch spacing, or 18-row planter with 30-inch spacing with a stack-fold configuration that requires anywhere from 180 to 310 Engine hp, based on planter size and desired speed.
2140 Pivot-Transport
A 23-, 24-, 31- or 32-row planter with 15-, 20- or 22-inch spacing with a split row configuration option that requires anywhere from 250 to 380 engine hp, based on planter size and desired speed. Available in wheeled or track carriers.

2150 Front Fold Trailing
A 12-, 16, and 24-row planter with 30 inch spacing that requires anywhere from 180-500 engine hp based on planter size and desired speed.
2150S Front Fold Trailing
Configurations include 23, 24, 31 or 32 rows with 15-inch spacing, or 24 rows with 20-inch spacing. Requires 180 to 500 engine horsepower based on planter size and desired speed.
2160 Large Front Fold Trailing
A 24-row planter with 30-inch spacing, 32-row planter with 30-inch spacing, 36-row planter with 20-, 22- or 30-inch spacing, or 47-row split-row planter with 15-inch spacing — available in wheeled or tracked carriers. Toolbars ranging from 60- to 90-feet require 380 to 620 engine horsepower, depending on planter size, desired speed and terrain.
